ARTITEQ Classic Rail with Installation Kit 20 kg/m (44 lbs/m)

The ARTITEQ Classic Rail is a heavy-duty, wall-mounted picture hanging system featuring a classic open J-shaped profile. Widely specified for commercial galleries, art exhibitions, schools, and traditional interiors, this open-top J-rail allows for the instant insertion of hanging rods, S-hooks, loop perlon wires, and cylinder hooks. Supporting up to 20 kg per metre, it provides a highly adaptable, robust presentation system for swapping and re-aligning artwork quickly without damaging wall surfaces.

Why Choose the ARTITEQ Classic Rail?

• Versatile Open J-Profile: Open-top channel allows hanging rods, S-hooks, and cylinder wires to drop directly into the track without sliding in from the ends.
• Heavy-Duty 20 kg/m Load Rating: Engineered from high-grade extruded aluminium to safely support medium-to-heavy gallery frames, exhibition canvases, and mirrors.
• Direct Screwed Fixing: Features pre-drilled wall mounting holes along the back flange for direct, flush-to-wall installation without clip-on brackets.
• Multiple Hanging Methods: Compatible with rigid 4 mm steel/aluminium hanging rods for heavy gallery exhibits or near-invisible 2 mm transparent perlon wires for discreet home displays.
• Durable Commercial Finishes: Available in Classic White, Matt Black, and Anodised Aluminium (Brushed Grey) to suit both modern and historic architectural spaces.

Technical Specifications

• Profile Type: Traditional open J-shaped rail profile.
• Track Lengths Available: 150 cm and 200 cm lengths (easily cut to size with a standard hacksaw).
• Rail Weight Capacity: Rated up to 20 kg per metre (44 lbs/m).
• Available Finishes: Pure White, Classic White, Matt Black, and Matt Grey (Anodised Aluminium).
• Fixing Type: Pre-drilled screw holes every ~50 cm along the rear flange.
• Profile Dimensions: 20 mm (Height) × 10 mm (Depth).

Compatible Hanging Hardware Options

Customise your Classic Rail setup using any of the following hardware combinations:

• S-Hook & Loop Wire System (15 kg Rating): Drop a steel S-Hook directly over the top rail edge, attach a 2 mm Loop Perlon Wire (20 kg), and slide on a Ratchet Hook (15 kg).
• Discreet Cylinder Hook System (15 kg Rating): Insert a compact Cylinder Hook into the J-channel with a 2 mm Hexagon Perlon Wire (15 kg) and pair with a Micro Grip Hook (20 kg).
• Rigid Gallery Rod System (Up to 20 kg Rating): Drop 4 mm aluminium J-rods or steel J-rods directly into the rail channel for high-capacity, rigid exhibition displays.

How to Install the Classic Rail

The Classic Rail is fixed directly to the wall through pre-drilled holes in the rear flange of the track.

1. Mark Installation Line: Use a spirit level to draw a straight horizontal guideline along your wall at your desired mounting height.
2. Mark Fixing Spots: Hold the J-profile against your line and mark the drill hole locations directly through the pre-drilled holes in the back flange (spaced ~50 cm apart).
3. Drill & Plug: Drill 6 mm holes at each marked spot and press the supplied FISCHER DuoPower wall plugs in until flush with the wall surface.
4. Secure Track: Position the rail over the holes and drive the screws directly through the pre-drilled track flange into the wall plugs until firmly secured.
5. Add Hardware: Fit matching end caps onto the open track ends, then drop your chosen S-hooks, cylinder wires, or gallery rods into the top channel.

What’s Included in the Box

• 1 × ARTITEQ Classic Rail Track 200 cm (20 kg/m Capacity)
• 4 × Installation Screws (3.5 mm × 45 mm) (per metre)
• 4 × FISCHER DuoPower Wall Plugs (6 mm × 30 mm) (per metre)
