The ARTITEQ Click Rail PRO offers a heavy-duty, commercial-grade solution for showcasing artwork while protecting your walls. Featuring an extra-thick aluminium profile engineered to support an impressive 50 kg per metre, this minimalist picture hanging track allows you to hang, slide, and rearrange heavy frames, canvases, and mirrors in seconds—eliminating the need for nails, drills, or plaster repairs. Whether you are outfitting a commercial gallery, a corporate office, or a modern residential space, the Click Rail PRO provides an invisible, high-capacity hanging track that keeps the visual focus entirely on your art.
Key System Benefits
50 kg/m Load Capacity — Reinforced extruded aluminium construction designed to safely support large exhibition pieces, heavy timber frames, and mirrors.
Click-and-Connect Technology — Snaps cleanly onto concealed wall brackets for a fast, level, and tool-free installation close to the ceiling line.
Discreet Architectural Profile — Sleek 28 mm × 11 mm track profile blends naturally against wall-ceiling junctions.
Custom Paintable Finish — The Pure White option can be painted with standard emulsion wall paint to match your room decor for a completely hidden appearance.
Damage-Free Versatility — Slide hanging cords laterally or adjust hook heights instantly without ever picking up a drill or damaging wall surfaces.
Technical Specifications
System Rating: 50 kg per metre (110 lbs/m)
Track Lengths: 100 cm, 150 cm or 200 cm (trim to size with a standard hacksaw)
Finishes: Pure White (Paintable) or Brushed Grey (Anodised Aluminium)
Dimensions: 11 mm (Depth) × 28 mm (Height)
Mounting: Wall-mounted flush beneath ceiling line
Wire Compatibility: Fits all 2 mm ARTITEQ Twister perlon cords and steel cables
Available Finishes & Custom Sizing
Pure White (Paintable): Offers complete creative freedom. Install as-is for a clean white border, or paint over it using standard interior wall paint to match your room exactly for an invisible look.
Brushed Grey (Anodised Aluminium): High-grade anodised finish featuring a soft metallic grain and mid-tone grey hue. Fingerprint and corrosion-resistant, perfect for concrete, timber, and industrial decor.
Wall-to-Wall Cutting: To achieve a flawless fit with zero gaps, cut the rail using a fine-toothed hacksaw. Subtract 5 mm clearance for each end cap (10 mm total allowance) when calculating wall-to-wall cuts.
How to Install the ARTITEQ Click Rail PRO
Brackets should be spaced every 40 cm along the wall. Watch our official ARTITEQ Click Rail PRO Video Installation Guide on YouTube for a visual walkthrough.
- Mark Line: Mark a straight horizontal line along your wall at 40 cm intervals.
- Drill Holes: Drill 6 mm holes into your marked mounting points.
- Insert Plugs: Press FISCHER DuoPower wall plugs firmly into the drilled holes.
- Mount Clips: Screw Click Rail PRO brackets firmly onto the wall using 3.5 mm × 40 mm screws.
- Fit End Caps: Push end caps onto the open ends of the track profile.
- Snap Track: Align the aluminium rail over the mounted brackets and press firmly until it clicks into place.
Professional Tip: When installing multiple rails continuously, place one bracket directly behind the joint where two rails meet to guarantee a flush alignment. Use corner connectors to run tracks around room corners seamlessly.
What’s Included in the Box
1 × ARTITEQ Click Rail PRO Track (50 kg/m Capacity)
2 × End Caps
3 × Click Rail PRO Installation Brackets (3 per metre)
3 × Installation Screws (3.5 mm × 40 mm) (3 per metre)
3 × FISCHER DuoPower Wall Plugs (6 mm) (3 per metre)
