D-Ring Picture Frame Hangers Triple-Hole incl. Fixings (Pack of 10)

The Triple-Hole D-Ring Picture Frame Hanger pack is engineered to provide superior structural reinforcement and weight distribution for large canvas frames, solid hardwood artwork, and heavy glass mirrors. Manufactured from heavy-gauge stamped steel with a corrosion-resistant electroplated finish, each wide strap features three pre-countersunk fixing holes. This triple-screw arrangement anchors firmly into timber mouldings to spread shear loads evenly across the wood grain, preventing pull-out and frame splitting under heavy downward forces.

Key System Benefits

Triple-Screw Weight Distribution — Three inline countersunk fixing holes distribute pulling force across a broader surface area of timber, preventing wood tear-out and keeping hangers rigidly aligned without twisting.

Heavy-Duty 20 kg Load Support — High-tensile steel construction safely supports substantial picture frames, oversized mirrors, and gallery display boards weighing up to 20 kg (44 lbs) per balanced pair.

Pivoting Wide D-Loop — The wide-profile hinged steel D-ring accommodates direct engagement onto wall hooks and picture rail hooks, or accepts heavy braided framing cord and steel wire.

Corrosion-Resistant Finishes — Available in electroplated Polished Brass or Bright Nickel finishes to protect hardware against rust, tarnish, and ambient moisture.

Complete Retail Hardware Kit — Supplied as a complete pack of 25 triple-hole strap hangers with 75 matching 3.5 mm × 12 mm countersunk wood screws for immediate installation.

Technical Specifications

Hanger Type: Heavy-gauge triple-hole D-ring strap plate
Dimensions: 36 mm (Height) × 28 mm (Width)
Hole Diameter: 4 mm countersunk screw holes (3 holes per hanger)
Fixing Screws Included: 3.5 mm × 12 mm countersunk wood screws (Qty 75)
Maximum Load Capacity: Up to 20 kg (44 lbs) per pair
Available Finishes: Polished Brass-Plated or Bright Nickel-Plated
Frame Material Compatibility: Solid timber, hardwood mouldings, softwood, and MDF frame profiles
Hanging Method Compatibility: Wall hooks, picture rail moulding hooks, braided cord, picture wire, and ARTITEQ drop cables

Simple Installation Guide

1. Measure and mark equal positions along the left and right rear vertical stiles of your wooden frame, approximately one-third down from the top edge.
2. Align each triple-hole plate vertically with the D-ring facing inward or slightly upward toward the frame centre.
3. Mark your pilot hole positions and drive three of the included 3.5 mm × 12 mm countersunk wood screws firmly into each strap until flush.
4. Link both D-rings using heavy-duty picture wire or cord, or mount the rings directly onto two level wall fixings or picture rail hooks.

Framing Pro Tip: For oversized mirrors or frames approaching the 20 kg threshold, hang the D-rings directly onto two independent wall anchors rather than spanning a single wire. This directs all load vertically downward and eliminates inward tensile pull on the side rails.

What’s Included in the Box

10 × Triple-Hole D-Ring Picture Frame Hangers (Select Brass or Nickel Finish)
30 × Wood Screws (3.5 mm × 12 mm)
